Feeding Plate:Turn the adjusting nut on the material tray shaft to install
the nose coil, and adjust the distance between the two nose wire coils at the same time.
Brake wheel:It is connected with the disc shaft to control the rotation of the disc.
Brake block: it controls the rotation of the disc by acting with the brake wheel.
Connecting block: connected with swing combination.
Swing rod: swing up and down to control the tension of nose wire.
The nose wire roll is placed on the nose wire discharge tray. The nose wire wheel rotates to drive the nose wire discharge wheel to rotate the feed. The nose wire passes through the tension floating combination device. When the nose wire is tightened, the swing bar starts to rise and the brake wheel device is released from the system. When the moving block is squeezed and the friction between the brake wheel and the brake block decreases, the feed speed of the material roll rotates faster, and the swing lever starts to fall, so that the friction between the brake wheel and the brake block increases, and the feed speed of the material roll rotates Slow down and cycle in this way.
